Description
Specifications
- Tube: Black smooth, highly abrasion resistant NR/SBR rubber compound.
- Reinforcement: High-strength synthetic plies.
- Cover: Wrapped impression, abrasion and weather resistant SBR rubber compound.
- Temperature Range: -40°C to +70°C.
- Application: Abrasive material handling.
Technical Parameters
| ID (inch) | ID (mm) | OD (mm) | WP (BAR) | WP (PSI) | BP (BAR) | BP (PSI) | W (gr/mt) | L (mt) |
|---|---|---|---|---|---|---|---|---|
| 3 1/8" | 80 | 90 | 5 | 75 | 15 | 225 | 1580 | 61 |
| 3 1/2" | 90 | 100 | 5 | 75 | 15 | 225 | 1825 | 61 |
| 4" | 101.6 | 112 | 5 | 75 | 15 | 225 | 2085 | 61 |
| 4 5/16" | 110 | 120 | 5 | 75 | 15 | 225 | 2163 | 61 |
| 5" | 127 | 137 | 5 | 75 | 15 | 225 | 2482 | 61 |
| 6" | 152.4 | 164 | 5 | 75 | 15 | 225 | 3506 | 61 |
| 8" | 203.2 | 215 | 5 | 75 | 15 | 225 | 4775 | 20 |
| 10" | 254 | 268 | 5 | 75 | 15 | 225 | 6859 | 20 |
| 12" | 305 | 319 | 5 | 75 | 15 | 225 | 8510 | 20 |
