Description
Specifications
- Application: Delivery of compressed air through pneumatic tools into the concrete mix.
- Tube: Black, smooth, synthetic rubber compound.
- Reinforcement: High strength synthetic plies.
- Cover: Black, wrapped impression, abrasion and weather resistant, synthetic rubber compound.
- Temperature Range: -40°C to +85°C ; -40°F to 185°F
Technical Parameters
| ID (inch) | ID (mm) | OD (mm) | WP (BAR) | WP (PSI) | BP (BAR) | BP (PSI) | W (gr/mt) | L (mt) |
|---|---|---|---|---|---|---|---|---|
| 3/4" | 19 | 30 | 10 | 150 | 30 | 450 | 570 | 61 |
| 1" | 25.4 | 36 | 10 | 150 | 30 | 450 | 840 | 61 |
| 1" | 25.4 | 39 | 10 | 150 | 30 | 450 | 950 | 61 |
| 1 3/16" | 30 | 42 | 10 | 150 | 30 | 450 | 930 | 61 |
