Description
Specifications
- Application: Suction and delivery of fatty liquids including milk, juice, soft drinks, or water-based products such as pharmaceuticals and cosmetics requiring an FDA grade hose. Also used for steam washdown.
- Tube: White, smooth, FDA approved NBR rubber compound.
- Reinforcement: High strength synthetic plies.
- Cover: Blue, wrapped impression, abrasion, weather and ozone resistant, synthetic rubber compound.
- Temperature Range: -40°C to +80°C ; -40°F to 176°F. Sterilization with 110°C (230°F) steam.
Technical Parameters
| ID (inch) | ID (mm) | OD (mm) | WP (BAR) | WP (PSI) | BP (BAR) | BP (PSI) | W (gr/mt) | L (mt) |
|---|---|---|---|---|---|---|---|---|
| 1/2" | 12.7 | 24 | 7 | 102 | 70 | 1020 | 488 | 61 |
| 5/8" | 16 | 28 | 7 | 102 | 70 | 1020 | 622 | 61 |
| 3/4" | 19 | 31 | 7 | 102 | 70 | 1020 | 707 | 61 |
| 1" | 25.4 | 37 | 7 | 102 | 70 | 1020 | 852 | 61 |
| 1 1/4" | 32 | 46 | 7 | 102 | 70 | 1020 | 1179 | 61 |
| 1 1/2" | 38 | 52 | 7 | 102 | 70 | 1020 | 1484 | 61 |
| 1 3/4" | 44.5 | 60 | 7 | 102 | 70 | 1020 | 1907 | 61 |
| 2" | 50.8 | 64 | 7 | 102 | 70 | 1020 | 2247 | 61 |
